Beschreibung
Gewicht 24,7 kg
Steuersatz ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface
Sattelklemme CUBE Semi-Integrated
Dämpfer Hardware Front: 30x8mm, Rear: DU-Bushing 12.7mm
Max. Systemgewicht 160 kg
Max. Fahrergewicht 125 kg
Rahmen C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
Größe S, M, L, XL
Federgabel Fox 38 Float Rhythm GRIP, Tapered, 15x110mm, E-Bike Optimized, 170mm
Motor Bosch Drive Unit Performance Line CX max. 100Nm (BDU38)
Remote Bosch Mini Remote
Akku Bosch PowerTube 800
Display Bosch Kiox 400C
Ladegerät Bosch 4A
Dämpfer Fox Float X Performance, 230x65mm, Adjustable LSR w/ 2-Pos. Lever
Bremsanlage Shimano XT BR-M8220, Hydr. Disc Brake (203/203)
Schaltwerk Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Schalthebel Shimano Deore SL-M6100, Rapidfire-Plus
Kurbelgarnitur ACID MTB Hybrid Pro, 36T
Kassette Shimano Deore CS-M6100, 10-51T
Kette KMC e12
Kettenführung Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Vorbau CUBE Performance Stem E-MTB 35, FPI-Link
Lenker CUBE Rise Trail Bar 35
Griffe ACID Disrupt, Soft Compound
Laufradsatz Newmen Performance 30 base/strong, 28/32 Spokes, 15x110mm / 12x148mm, Tubeless Ready
Vorderreifen Conti Argotal, Enduro Soft, Tubeless Ready, 2.4
Hinterreifen Conti Kryptotal Rear, Downhill Soft, Tubeless Ready, 2.4
Sattel ACID Venec EMTB Trail 140
Sattelstütze CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
Pedale ACID PP MTB
Farbe blackline
