Beschreibung
Frame Series 3 6061 Aluminum, 27.5 or 29″ Wheels, 130mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
Front Suspension X-Fusion Slide (29) or Sweep(27.5) Boost RC, 140mm Travel, Compression and Rebound Adjustment, 44mm Offset
Rear Suspension X-Fusion O2 Pro R, Custom Tune, 210x55mm, M8x25mm Hardware Top and Bottom
Rims Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Hub, Rear Shimano HB-MT200B, 141 QR, Centerlock, Standard Freehub Body
Hub, Front Shimano HF-MT400B, 110x15mm, Centerlock
Tires Vee Tire Snap WCE 2.35″, Top 40 Compound, GXE Core, 90 TPI, Tubeless compatible
Derailleur, Rear Shimano RD-U6000, 11-Speed GS
Shift Lever Shimano, SL-U6000-11R, 11-Speed
Crankset Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, 170mm Crank Length, Boost Spacing
Chain Shimano LG-500 11-Speed
Brake, Front Tektro HD-M280 Hydraulic Disc, 180mm Rotor
Brake, Rear Tektro HD-M280 Hydraulic Disc, 180mm Rotor
Brake Levers Tektro HD-M280
Handlebar Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
Stem Marin 3D Forged Alloy, 35mm
Grip Marin MTN, Closed End
Headset FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8″ x 1 1/2”
Seatpost X-Fusion Manic, 1x Composite Remote, Size XS-S 150mm Travel, Size M-XL 170mm Travel, 30.9mm
Saddle Marin Speed Concept
